Connectors
Connector A: USB Type C Male
Connector B: DisplayPort Male
Housing Material: USB C: PVC, DP: ABS shell
Connector Plating: Gold plating
Pin Construction: Copper alloy
Pin Plating: Gold plating
Dimensions (approx.) WxDxH:
USB: 32x12x6.3mm (1.26x0.47x0.25in)
DP: 47.17x21.8x9.2mm (1.86x0.86x0.36in)
Cable construction
Length: 3m
Standard: DP 1.2
Colour: Black
Type: Round
Jacket Diameter: 5mm (0.20in)
Jacket Material: PVC
Conductor Material: Tinned Copper
Conductor Gauge: 32AWG
Shielding: Copper Braid 85%
Specifications
Chipset: LT87101CD
Supported Bandwidth: 21.6Gbps
Power Delivery: -
Maximum Resolution: 3840x2160@60Hz 10bit 4:4:4
Nominal Attenuation: 0.1MHz-6MHz<12DB
Minimum Bend Radius: 47mm (1.85in)
Operating Temperature: 0°C - 35°C (32°F - 95°F)
Storage Temperature: 0°C - 45°C (32°F - 113°F)
Miscellaneous
Packaging Type: Polybag
Warranty (Years): 2
Product Compliance: CE, FCC, RoHS, REACH, California Proposition 65
