Inputs
1 HDMI: On a female HDMI connector
Outputs
1 HDMI: On a female HDMI connector
Ports
1 Ethernet: On an RJ–45 connector
1 Ethernet: On an SFP optical/copper transceiver port
1 Balanced Audio: On a 5–pin terminal block connector
1 RS-232: On a 3–pin terminal block connector
1 IR: On a 3.5mm TRS connector
USB
1 USB-B Host: Connecting USB 3.0 PC/Laptop
1 USB-C Host: Connecting USB 3.0 PC/Laptop. Charges connected hosts that support USB Power Delivery 2.0, up to 60W, when the device is powered by the optional PS–2006 20V DC power adapter
2 USB-A Devices: Connecting USB 3.0 local devices
1 Level USB Hub: When connecting to KDS–17DEC
Network
Multicast: Through RTSP (Real Time Streaming Protocol): IGMP snooping non–blocking, Layer 2
Unicast: Through RTSP (Real Time Streaming Protocol)
Bitrate: Peak: 850Mbps, 4K average: 350Mbps, 1080p average: 250Mbps
Video
Compression Standard: JPEG2K–Like, private stream
Max Resolution:
4K@60Hz (4:4:4)
HDR 10: Up to 4K30 4:2:2 12 bit
EDID: Passthrough, output resolution, predefined default EDID, or custom EDID
Resolution
4096x2160@60Hz 1600x1200@60Hz 1280x960@60Hz 848x480@60Hz3840x2160@60Hz 1600x900@60Hz 1280x800@60Hz 800x600@60Hz1920x1200@50Hz 1440x900@60Hz 1280x768@60Hz 720x576@60Hz1920x1080@60Hz 1400x1050@60Hz 1280x720@60Hz 720x480@50Hz1856x1392@60Hz 1366x768@60Hz 1224x768@70Hz 640x400@85Hz1792x1344@60Hz 1360x768@60Hz 1152x864@70Hz 640x350@85Hz1680x1050@60Hz 1024x768@60HzAudio
Supported Formats: LPCM, Dolby and DTS
LPCM: LPCM upto 7.1/24–bit/192kHz
Dolby: Dolby AtmosTM, Dolby TrueHD, Dolby Digital PlusTM, Dolby Digital EX, Dolby Digital 5.1, Dolby Digital 2/0 Surround, Dolby Digital 2/0
DTS: DTS–HD Master AudioTM, DTS–HD, DTS–ES Discrete 6.1, DTS–ES Matrix 6.1, DTS Digital Surround 5.1
Security
HTTPS, 802.1x, OWASP–10, AV Streaming: AES256 encryption
User Interface
Indicators: LINK, NET and ON LEDs, front panel LCD Display
Rear Panel: Restart and factory reset rear panel button
Controls: Embedded web pages, P3K API commands via Ethernet, front panel navigation buttons
Power
PoE+: 37V to 57V, maximum power 15W
Optional power supply: 20V DC, 6A
Optional power supply: Charger PS–2006 is required when using USB–C to charge connected hosts that support USB Power Delivery 2.0, up to 60W
Environmental Conditions
Operating Temperature: 0 to + 45°C (32 to + 113 °F)
Storage Temperature: –20 to +70°C (–4 to + 158 °F)
Humidity: 10% to 90%, non–condensing
Regulatory Compliance (Standards Compliance)
Safety: CE,FCC
Environmental: RoHs, WEEE, UKCA
