PT-1C er en 4K@60Hz (4:4:4) HDCP 2.2 HDMI EDID Prosessor
Den lar deg låse EDID og velge om HDCP, Multi-kanals lyd eller Deep Color-signaler skal støttes. På den måten kan man sette opp en EDID som passer med skjermen eller oppsetet man bruker og løse evt. kompatibilitetsproblemer i felten.
- Maks båndbreddede — 17.82Gbps
- Støtter opp til 38140x210@60Hz (4:4:4).
- HDCP 2.2 Compliant.
- Får strøm fra HDMI-kilde
- 4 dip-switcher for valg av paramtetre
DIP-switcher:
- DIP 1 passes the EDID or locks the entire EDID file of the connected display at the time of the locking action (with the relevant changes done by DIP 2 and 3). DOWN = passes EDID Switching UP = locks the EDID of the currently connected display (with modification according to DIP 2 and DIP 3) UP = uses the locked EDID file (ignore the EDID of the currently connected display)
- DIP 2 controls deep color: DOWN = passes the deep color EDID parameter (set DIP 1 ON to activate state) UP = limits the color depth to 8-bits per color
- DIP 3 controls audio: DOWN = passes the audio EDID parameter (set DIP 1 ON to activate state) UP = limits the audio to 2-channel LPCM (linear pulse code modulation)
- DIP 4 controls HDCP: DOWN = passes HDCP UP = HDCP off
Lagre EDID fra monitor:
Put all Dips ON ( down position )
Connect laptop – PT-1C - Display and wait to see picture.
Turn OFF Dip1 ( Up position ) and wait 3 seconds
The Display1 EDID will be stored without any changes and locked.
You can disconnect the PT-1C and reconnect to it to any other display and the Disply1 EDID wont change until you will run the procedure again and overwrite it.
