Inputs
1 HDMI:
On a female HDMI connector
Ports
HDBaseT 3.0
Output port
1 RS-232:
On a 3–pin terminal block connector for serial link extension
1 IR:
On a 3.5mm mini jack connector
Extension Line
Standard Compression
Up to 40m (130ft) at 4K@60Hz (4:4:4)
High Compression
Up to 70m (230ft) at 4K@30Hz (4:4:4) or full HD (1080p @60Hz 36bpp)
Standards Compliance
HDBaseT 3.0
Note
When using recommended Kramer cables
Video
Max Data Rate:
Up to 18Gbps (6Gbps per graphic channel)
Compliance:
HDCP 2.3, HDR 10
HDMI Support
Deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0b
EXTENDED BIDIRECTIONAL RS-232
300 to 115200 baud rate
EXTENDED BIDIRECTIONAL IR
20kHz to 100kHz frequency
User Interface
Indicators:
IN, OUT, LINK and ON LEDs
Controls:
DIP–switches
Power
Source:
48V DC
Consumption:
330mA
Environmental Conditions
Operating Temperature:
0° to +40°C (32° to 104°F)
Storage Temperature:
–40° to +70°C (–40° to 158°F)
Humidity:
10% to 90%, RHL non–condensing
Regulatory Compliance (Standards Compliance)
Safety:
CE, UL
Environmental:
RoHs, WEEE
Enclosure
Size:
DigiTOOLS®
Type:
Aluminum
Cooling:
Convection ventilation
Accessories
Included:
Power adapter, power cord, bracket set
General
Product Dimensions
12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H
Product Weight
0.3kg (0.6lbs) approx.
Shipping Dimensions
49.00cm x 18.60cm x 58.80cm (19.29" x 7.32" x 23.15" ) W, D, H
Shipping Weight
0.7kg (1.5lbs) approx.
Product Dimensions
PRODUCT DIMENSION:
12.00cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96" ) W, D, H
Product Weight
PRODUCT WEIGHT:
0.3kg (0.6lbs) approx.
