Audio
Driver:
LF Driver:
165 mm (6.5”) driver with polypropylene cone and rubber surround
HF Driver:
25mm (1") soft dome with dampening, ferrofluid — cooled
Frequency characteristics
Frequency Range (-10dB):
60Hz–20kHz
Frequency Response (±3dB):
84Hz–20kHz
Dispersion angle:
126deg. (1 kHz to 4 kHz)
Power handling:
PoE++:
10W continuous / 30W peak
PoE+:
10W continuous / 20W peak
PoE:
10W continuous / 10W peak
Sound Pressure Level (SPL):
Sensitivity (1W@1m, free field):
90dB SPL
PoE++ :
Continuous: 100dB / Peak: 105dB
PoE+ :
Continuous: 100dB / Peak: 103dB
PoE :
Continuous: 100dB / Peak: 100dB
MECHANICAL
Installation
Type:
Surface mounted vertical, horizontal or in corners
Mounting:
EasyMount bracket included, standard 75mm VESA mount threads
Connectors:
RJ–45, factory reset button
Dimensions
Dimensions without Bracket:
200mm x 182mm x 310mm / 7.17” x 6.63” / 12.2”
Dimensions with Bracket:
200mm x 246mm x 310mm / 7.17” x 9.67” / 12.2”
Shipping dimensions (single unit):
342mm x 292mm x 400mm / 13.5" x 11.5" x 15.8"
Shipping dimensions (2 units in a Master box):
592mm x 352mm x 418mm / 23.3" x 13.9" x 16.5"
Shipping weight (single unit):
4.2Kg / 2.2lbs
Shipping weight (Master box):
9.1Kg / 20.1lbs
Material
Grill:
Powder Coated Steel, removable logo
Baffle & back enclosure:
V–0 Flame Retardant
Bracket
Aluminum
Environmental
Operating Temperature:
–5° to +50°C (23°F to 122°F.)
Storage Temperature:
–10° to +55°C (14°F to 131°F.)
Humidity:
30% to 85%, RHL non–condensing
Weight per single speaker (including mounting bracket)
2.9kg (6.3lbs)
REGULATORY
Safety
U1480A Compliant:
Safety standards for fire–protective signaling in commercial spaces.
IEC 62368 (CB) / CE LVD:
Safety standard for audio equipment addressing risks related to electrical, mechanical, and environmental factors in low–voltage devices.
UL 62368-1:
Safety of audio, equipment by addressing potential hazards through risk–based performance criteria for electrical and mechanical systems.
BIS (India):
Safety, quality, and performance requirements specific to the Indian market.
RCM:
(Regulatory Compliance Mark) electrical safety, electromagnetic compatibility (EMC), and radiofrequency (RF) standards for products in Australia and New Zealand.
EMI
FCC / IC:
Compliance with regulations for electromagnetic interference (EMI) and radio frequency (RF) emissions, ensuring that devices operate safely and do not cause harmful interference.
Environmental:
RoHS, REACH, WEEE
