Video
HDMI 2.0 with HDCP pass–through
Audio (Digital)
Encoded audio formats and linear PCM up to 8 channels
Audio (Analog)
Balance Stereo (5–pin phoenix) Output
Serial (RS232)
3–pin phoenix
USB
Dual USB 2.0 (USB — A connectors) Note: HID Support Only
Ethernet
10 Gb for Video/Audio/Control with 1 Gb Utility
Formats
Supports all major VESA resolutions and variations including full HDMI 2.0
Support:
VGA: 640x480 (4:3)
SXGA: 1280x1024 (5:4)
1080p/i: 1920x1080 (16:9)
SVGA: 800x600 (4:3)
WXGA: 1366x768 (16:9)
QXGA: 2048x1536 (4:3)
XGA: 1024x768 (4:3)
SXGA+: 1440x1080 (4:3)
Ultra HD: 3840x2160 (16:9)
HDTV: 1280x720 (16:9)
UXGA: 1600x1200 (4:3)
4K: 4096x2160 (17:9)
Custom resolutions are supported at pixel clock rates up to 600 MHz
Video Other
Color depth: 24 bit, 30 bit, 36 bit, 48 bit
Video Wall and Multiview
Video Wall up to 15x15. Multiview with up to 19 sources
Signal transmission distance
Cat6a: 100m
Copy Protection/Security
HDCP 2.3, AES–128 Encryption, 802.1X compatible
Power input (locking connector)
12V DC
Power
Approximately 13 watts
Dimensions (L x W x H) / Weight
7.8 in (199mm) x 5.4 in (136mm) x 1.9 in (48mm), 35.2 oz (1000g)
Temperature
Operating temperature: 32 F to 104 F <0 C to +40 C>
Storage temperature: — 4 F to +176 F <–20 C to +80 C>
Humidity
Operating/ Storage: 20% to 90% (Non–Condensing)
