Type
Active
Peak output power
1200 W
RMS output power
300 W
Amp class
Class D
Max. SPL peak (sine burst, fullspace/1 m, THD=10 %)
129 dB
Max. SPL average (sine burst, BW, fullspace/1 m, THD=10 %)
122 dB
Frequency response (-3 dB, rel. Avg)
58 - 18,000 Hz
Frequency response (-10 dB, rel. Avg)
48 - 20,000 Hz
Speaker system
2-way coaxial system
Crossover frequency
1300 Hz
Beam angle
Hor.: 50° / Vert.:90°
Monitor angle
33 °
Number of inputs
2
Input connector types
6.3 mm Jack TRS female
Number of outputs
2
Output connector types
XLR 3-pole female
Protection features
Multiband Limiter, Overheating, Overvoltage, Overload
Colour
Black
Inputs
Number of line inputs
2
Outputs
Number of line outputs
2
Line outputs connector type
XLR 3-pole female
Signal processing
Mixer
Yes
Audio processing
3 band EQ (High, Mid, Low), Delay Line, Notch filter, Presets
Bass driver
Size
15 "
Outer diameter
381 mm
Magnet
Ferrite
Voice coil
3 "
Mid range
Outer diameter
381 mm
Magnet
Ferrite
Tweeter
Driver size
1 "
Outlet diameter
25.4 mm
Magnet
Ferrite
Voice coil
1.75 "
Mains operation
Operation voltage
100 V AC - 230 V AC / 50 - 60 Hz
Power supply type
External switched-mode power supply (SMPS)
Rated power
150 W
Mains connector
Mains socket indoor power in male & powerCON®
Mains fuse
T4AL/250 V
Housing
Design
Bass reflex
Number of handles
2
Flange
36 mm (0°/5°)
Cabinet material
Birch multiplex, Medium-density fibreboard MDF
Material thickness
15 mm
Front grille material
Aluminium
Environmental
Ambient temperature
0 - 40 °C
Maximum air humidity (non-condensing)
80 %
