Connectors
Connector A: USB Type A Male
Connector B: USB Type C Male
Power Consumption: 1.5W
Housing Material: PVC
Connector Plating: Nickel, Stainless Steel (Type C), SPCC + Nickel (Type A)
Pin Construction: Copper Alloy + Mating Area Au
Pin Plating: Gold Flash (Type C), Copper Alloy (Type A)
Dimensions (approx.) WxDxH:
Type A: 47.5x8.2x18.5mm (1.87x0.32x0.73in)
Type C: 45x8.2x14.5mm (1.77x0.32x0.57in)
Cable Construction
Length: 50m
Standard: USB 3.2 / 3.1 Gen 1
Colour: Black
Type: Round
Jacket Diameter: 4.9mm (0.19in)
Jacket Material: TPE
Conductor Material: Bare Copper & Tinned Copper
Conductor Gauge: 24/28/30AWG
Shielding: AL Foil and Copper Braid
Specifications
Supported Bandwidth: 5Gbps
Nominal Attenuation: -
Minimum Bend Radius: Dynamic/Static: 25mm/12.5mm
Maximum Tensile Load: Long Term/Short Term: 100N/200N
Operating Temperature: -20°C to 70°C (-4°F - 158°F)
Storage Temperature: -30°C to 75°C (-22°F - 167°F)
Transmission Medium: USB 3.0 Fiber & USB 2.0 Copper Wire
Transmission Technology: Optical/Electrical
