Specifications:
AV Interface: HDMI® to USB Type C with DisplayPort 1.2 Alternate Mode
Supported Bandwidth: HDMI® 2.0 with 18Gbps
Maximum Input Resolution: 3840x2160@60Hz
Maximum Output Resolution: 3840x2160@60Hz
Chipset: LTD6711A
HDCP Support: HDCP 1.3
Supported Audio: Stereo LPCM 192kHz 24bit
Separate Audio Ports: -
Special Features: Supports touch control
Connectors
Input: HDMI® Type A Male, USB Type C for power
Output: USB Type C Female
Physical properties
Dimensions (approx.) WxDxH:
Housing: 71.7x31.3x12mm (2.82x1.23x0.47in)
HDMI®: 29.7x17.8x8.8mm (1.16x0.7x0.35in)
(Fixed) Cable Length: 200mm (7.87in)
Housing Material: ABS
Jacket Material: PVC
Jacket Diameter: HDMI: 4.8mm (0.19in)
Minimum Bend Radius: 48mm (1.89in)
Net Weight: 0.029kg (0.06lb)
Operating Temperature: 0°C to 45°C (32°F - 113°F)
Storage Temperature: -10°C to +80°C (14°F - 176°F)
Humidity: 10 - 85% RH (non-condensing)
Colour: Black
Miscellaneous
Packaging Type: Polybag
Packaging Dimensions: 174x20x194mm (6.3x0.79x7.64in)
Gross Weight: 0.06kg (0.13lb)
Warranty (Years): 2
Product Compliance: CE, FCC, RoHS, REACH, California Proposition 65
