Specifications
AV Interface: Type C
Interface Standard: USB 2.0
Supported Bandwidth: 18Gbps
Available USB Bandwidth: 350Mbps
Maximum Distance: 100m (328.08ft)
Maximum Resolution:
- 70m (229.66ft) - 3840x2160@60Hz 4:4:4 8bit
- 100m (328.08ft) - 3840x2160@30Hz 4:4:4 8bit / 4:2:2 12bit
HDCP Support: 2.2
EDID Pass Through: APIs with presets, user defined and copy function
Supported Audio: Pass Through
Separate Audio Ports: -
IR Support: -
CEC Support: -
Serial Interface: RS-232 Pass Through
Transmission Protocol: HDBaseT 3.0
Transmission Medium: Cat.6A
Laser Class (only for Fibre): -
Wavelength (only for Fibre): -
Chipset: VS3000
Special Features: DisplayPort Alternate mode, APIs, 100W PD on Type C port, PoC (Power over Cable) with On/Off switch
Connectors
Transmitter Input: USB Type C Alt Mode (Female), USB Type C PD (Female)
Transmitter Output: RJ-45 (Female), 2x USB Type A (Female)
Receiver Input: RJ-45 (Female)
Receiver Output: USB Type C Alt Mode (Female), 2x USB Type A Device (Female), USB Type C Device (Female)
Control Ports: USB Type C (Female), RS-232 3-Pin Terminal Block
Power: 5.5/2.1mm
Physical Properties
Dimensions (approx.) WxDxH: 120x117x25.5mm (4.72x4.61x1in)
Housing Material: Metal
Net Weight: 1.8Kg (3.97lb)
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -20°C - 60°C (-4°F - 140°F)
Humidity: 20 - 80% RH (non-condensing)
Power Requirements: 24VDC 3.75A
Colour: Black
Miscellaneous
Packaging Type: Carton Box
Packaging Dimensions: 320x180x80mm (12.6x7.09x3.15in)
Gross Weight: 2.06Kg (4.54lb)
Warranty (Years): 3
Product Compliance: CE, UKCA, FCC, RoHS, REACH & California Proposition 65
