Camera
Image Sensor
1/2.8” Sony Exmor™ CMOS
Total Picture Elements
8.59 Megapixels
Effective Picture Elements
8.45 Megapixels
Output Resolutions
4K/30**, 4K/29.97**, 4K/25**, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50
Minimum Illumination
0.5 lux (IRE50, F1.6, 30fps)
S/N Ratio
= 50 dB
Gain
Auto, Manual
TV Line
4K**: 1200 (Center)
1080p: 900 (Center)
Shutter Speed
1/1 to 1/10,000 sec
Exposure Control
Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance
Auto, Manual, ATW, One Push, Indoor, Outdoor
Optical Zoom
22X
Digital Zoom
12X
Total Zoom
264X
Viewing Angles
DFOV: 78.3° (Wide) to 3.27° (Tele)
HFOV: 70.4° (Wide) to 2.86° (Tele)
VFOV: 42.7° (Wide) to 1.61° (Tele)
Focal Length
f = 4.3 mm (Wide) to 94.6 mm (Tele)
Aperture (Iris)
F = 1.6 (Wide) to 4.2 (Tele)
Minimum Working Distance
0.01 m (Wide), 1.2 m (Tele)
Pan / Tilt Angles
Pan: ±170°, Tilt: +90° / -30°
Pan / Tilt Speed (Manual)
Pan: 0.1° to 100° / sec, Tilt: 0.05° to 100° / sec
Preset Speed
Pan: 200° / sec, Tilt : 200° / sec
Preset Positions
10 (IR), 256 (RS-232 / RS-422 / IP)
Camera Control - Interface
RS-232 (DIN8), RS-422 (RJ45), IP, USB
Camera Control - Protocols
VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP), USB, ONVIF
Image Processing
Noise Reduction (2D / 3D), Flip, Mirror, WDR, BLC
Power Frequencies
50 Hz, 60 Hz
Wide Angle Camera
Image Sensor
1/2.8” CMOS
Effective Picture Elements
2 Megapixels
Output Resolutions
1080p/30
Focal Length
2.22 mm
White Balance
ATW
Exposure
Auto
Viewing Angles
DFOV: 113
HFOV: 105°
VFOV: 71°
Pan / Tilt Angles
Tilt: +10° / -10°
AI Technology
Auto Tracking Modes
Presenter Mode, Zone Mode, Hybrid Mode
AI Features
Multi-Presenter Detection, Multi-Presenter Tracking
Privacy Protection Mechanisms
Protection Mode
Sleep Mode
Audio
Channel
2ch Stereo
Codec
AAC-LC (48 K)
Sample Rates
48 KHz
Interface
Video Outputs
3G-SDI, HDMI®, IP, USB
Audio Outputs
3G-SDI, HDMI®, IP, USB
Audio Inputs
Mic in, Line in
General
Power Requirement
AC 100 - 240V to DC 12V/2A
Power Consumption
19W
PoE
PoE+ (IEEE802.3at)
Dimensions (W x H x D)
180.9 x 204.6 x 182.1 mm
Net Weight
2.1 (±0.1) kg
Application
Indoor
Tally Lamp
Yes
Security
Kensington Slot
Remote Control
Infrared
Operating Conditions
Temperature : 0 °C to +40 °C ; Humidity : 20% to 80%
Storage Conditions
Temperature : -20 °C to +60 °C ; Humidity: 20% to 95%
IP Streaming
Resolution
Up to 4K 30fps**
Network Video Compress Formats
H.264, H.265, MJPEG
Network Audio Compress Formats
AAC-LC (48 K)
Maximum Frame Rate
Up to 4K 30fps**
Bit-Rate Control Modes
VBR, CBR (selectable)
Range of Bit-Rate Setting
512 Kbps to 120 Mbps
Network Interface
10 / 100 / 1000 Base-T
Multi-Stream Capability
Up to 4K 30fps**
Standard Mode, Zoom Mode, NDI® Mode: 5 (RTSP, HDMI®, USB, 3G-SDI***, & NDI®)
Teams Mode: 1 (USB)
Network Protocols
IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP, ONVIF
NDI
®
HX3
Yes (Pre-installed)
NDI
®
Embedded Bridge
Yes
Dante
®
AV-H
N/A
Camera Tracking Data Output
Supports Free-D Type D0 / D1
USB
Connector
USB 3.2 Gen 1 Type-B
Video Format
MJPEG, YUY2
Audio Format
PCM
Maximum Video Resolution
Up to 4K**
USB Video Class (UVC)
UVC 1.1
USB Audio Class (UAC)
UAC 1.0
Web UI
Live Video Preview
Yes
Camera PTZ Control
Pan, Tilt, Zoom, Focus, Preset Control
Camera / Image Adjustment
Exposure, White Balance, Picture
Network Configuration
DHCP, IP Address, Gateway, Subnet Mask, DNS
Supported Web Browsers
Chrome™, Microsoft Edge, Safari®
Software Tools
Device Utility
Supports Windows® 10 or later, macOS® 11.6 or later
Enterprise Management
Supports Windows® 10 or later
Room Management
Supports Windows® 10 or later, macOS® 11.6 or later
Cloud Management
Supports Chrome™ & Microsoft Edge browsers
Control Panel
Supports iOS & iPadOS® 11 or later
OBS Plugin for PTZ Cameras
Supports Windows® 10 or later, macOS® 11.6 or later
CaptureShare
Supports Windows® 10 or later, macOS® 11.6 or later
