Inputs
2 DP Alt Mode & PD 3.0 USB-C: On a USB type–C female connector
2 HDMI: On an HDMI female connector
Outputs
2 HDMI: On an HDMI female connector
1 Balanced Stereo Audio Line: On 5–pin terminal block connector
1 IR: On a 3.5mm mini jack for IR extension
Ports
2 USB 3.2 Host: On a USB–C female connector
2 USB 3.2 Host: On a USB–B female connector
3 USB 3.2 Device: On USB type–A female connectors
1 Ethernet: On an RJ–45 female connector for LAN connection
1 RS–232: On a 3–pin terminal block
2 GPIO: On a 2–pin terminal block
Video
Max Data Rate: 18Gbps bandwidth (6Gbps per graphic channel)
Max Resolution: 4K@60Hz (4:4:4) resolution
Content Protection: HDCP 2.3
HDMI Support: Deep Color, 3D, HDR as specified in HDMI 2.0b
USB Features
USB 3.2 Data Rate: Up to 10Gbps
Integrated USB Hubs: 1
Standards Compliance: USB 3.2 GEN 2, 2.0 and 1.1
Analog Audio
Max Output Signal Level: 14.5dBu
Impedance: 500?
Bandwidth: 20Hz — 20kHz
Crosstalk: –114dB
THD + N: 0.005% @1kHz at nominal level
S/N Ratio: 85dB, 20Hz — 20kHz
Coupling: DC
Power
Power Adapter (included):
Source: 20V DC, 12A
Max. Power:
No external power delivery: 5.8W
Maximum deliverable power to external devices: 178W
Max. Heat Dissipation
With no external power delivery: 19BTU/hr (5.5W)
With maximum external power delivery: 47BTU/hr (14W)
USB Device Charging
USB-C port 1: 100W
USB-C port 2: 60W
Environmental Conditions
Operating Temperature: 0° to +40°C (32° to 104°F)
Storage Temperature: –40° to +70°C (–40° to 158°F)
Humidity: 10% to 90%, RHL non–condensing
Regulatory Compliance (Standards Compliance)
Safety: CE, UL
Environmental: RoHs, WEEE
