Specifications
Camera
Image Sensor
1/2.8' CMOS
Effective Picture Elements
8 Megapixels
Output Resolutions
Resolutions: 4K / 1080p / 720p
Frame Rates: 60 / 59.94 / 50 / 30 / 29.97 / 25
Minimum Illumination
0.5 lux (50 IRE, F1.6, Max. AGC, 1/30)
S/N Ratio
= 50 dB
Gain
Auto, Manual
TV Lines
1000 (Center / Wide)
Shutter Speed
1/1s to 1/10,000s
Exposure Control
Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance
Auto / Manual
Optical Zoom
20X
Digital Zoom
1X
Total Zoom
20X
Viewing Angles
DFOV: 69.2° (Wide) to 4.1° (Tele)
HFOV: 62.3° (Wide) to 3.6° (Tele)
VFOV: 37.7° (Wide) to 2.1° (Tele)
Focal Length
f = 4.5 mm (Wide) to 90 mm (Tele)
Aperture (Iris)
F = 1.8 (Wide) to 4.7 (Tele)
Minimum Working Distance
0.1 m (Wide) , 1.2 m (Tele)
Pan / Tilt Angles
Pan: ±170°, Tilt: +90° / -30°
Pan / Tilt Speed (Manual)
Pan: 0.1° to 100° / sec, Tilt: 0.1° to 100° / sec
Preset Speed
Pan: 200° / sec, Tilt: 200° / sec
Preset Positions
10 (IR), 256 (RS-232, RS-422, IP)
Camera Control - Interfaces
RS-232 / RS-422 / Ethernet
Camera Control - Protocols
VISCA (RS-232 / RS-422 / IP), CGI (IP)
Image Processing
Mirror / Flip / Freeze / WDR / BLC
Power Frequencies
50 Hz, 60 Hz
AI Function
Mode
Eye Tracking
Privacy
Protection Mode
Privacy Mode, Privacy Indicator
General
Power Requirement
12V
Power Consumption
24W
PoE
PoE+ (IEEE802.3at)
Dimensions
180(W) x 145(D) x 183.5(H) mm
Net Weight
1.7 ± 0.1 kg
Housing Material
Anti-UV
Application
Indoor
IR Night Vision
Yes
Security
Kensington Slot
IR Remote Control
Yes
Operating
Temperature: 0 °C to +40 °C
Humidity: 20% to 80%
Storage Conditions
Temperature: -20 °C to +60 °C
Humidity: 20% to 95%
Audio
Channels
2ch Stereo
Codec
AAC-LC (48K)
Built-in Microphone
1 (Omni-Directional)
Interface
Video Outputs
HDMI, IP, USB
Audio Outputs
HDMI, IP, USB
Audio Inputs
N/A
IP Streaming
Resolution
4K 60fps
Network Video Compress Formats
H.264, H.265, MJPEG
Maximum Frame Rate
4K 60fps
Bit-Rate Control Modes
VBR, CBR
Range of Bit-Rate
512Kbps to 64Mbps
Network Interface
10 / 100 / 1000 Base-T
Multi-Stream Capability
2 (RTSP / Web page), 4K 60fps Max.
Network Protocols
IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP RTP/RTCP, RTSP, RTMP,VISCA over IP
USB
Connector
USB 3.0 (Type-B)
Video Formats
MJPEG
Maximum Video Resolution
2160p
USB Video Class (UVC)
UVC 1.1
USB Audio Class (UAC)
UAC 1.0
Web UI
Live Video Preview
Yes
Camera PTZ Control
Pan, Tilt, Zoom, Focus, Preset Control
Camera / Image Adjustment
Exposure, White Balance, Picture
Network Configuration
DHCP, IP Address, Gateway, Subnet Mask, DNS
Software Tools
IP Search and Configuration Tool
Support Windows® 7 or later
ViewCare
Support Windows® 7 or later
PTZ Control Panel
Supports iOS & iPadOS® 11 or later
Camera Setting Tool
Supports Windows® 7 or later, macOS® 10.14 or later
