Specifications
Camera
Image Sensor
1/2.8' 4K Exmor CMOS
Effective Picture Elements
8 Megapixels
Output Resolutions
4K/30 (IP/UVC only), 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30
Minimum Illumination
0.7 lux (IRE50, F1.6, 30fps)
S/N Ratio
= 50 dB
Gain
Auto, Manual
Shutter Speed
1/1 to 1/10,000 sec
Exposure Control
Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance
Auto, Manual
Optical Zoom
30X
Viewing Angles
DFOV: 75.5° (Wide) to 3.1° (Tele)
HFOV: 68.0° (Wide) to 2.7° (Tele)
VFOV: 41.7° (Wide) to 1.5° (Tele)
Focal Length
f = 4.3 mm (Wide) to 129 mm (Tele)
Aperture (Iris)
F = 1.6 (Wide) to 4.7 (Tele)
Minimum Working Distance
0.01 m (Wide), 1.2 m (Tele)
Pan / Tilt Angles
Pan: ±170°, Tilt: +90° / -35°
Pan / Tilt Speed (Manual)
Pan: 0.1° to 100° / sec, Tilt: 0.1° to 100° / sec
Preset Speed
Pan: 200° / sec, Tilt: 200° / sec
Preset Positions
10 (IR), 256 (RS-232 / IP)
Camera Control - Protocols
VISCA (RS-232 / IP), PELCO-D & PELCO-P (RS-232), CGI (IP)
Image Processing
Noise Reduction (2D / 3D), Flip, Mirror, WDR, BLC
Power Frequencies
50 Hz, 60 Hz
Speaker
Embedded Speaker
Yes
SPL
77 dB SPL (1W / 1m)
Maximum SPL
90 dB SPL at 0.5 m
Microphone
Built-in Microphone
2 (Omnidirectional)
AI Noise Reduction
Yes
Sensitivity
-33 dBFS
Frequency Response
20 Hz to 20 KHz
Maximum SPL
133 dB SPL at 0.5 m
Loop Recording
Resolution
Up to 4K
Length of Video
5 minutes
Recording Modes
Loop & continuous
Loop Mechanism
Wipe the oldest clip
Interface
Video Outputs
HDMI, IP, USB
Audio Outputs
HDMI, IP, USB
General
Power Requirement
AC 100 - 240V to DC 12V/3.34A
Power Consumption
36W
Dimensions (W x H x D)
168.0 x 205.0 x 126.0 mm
Net Weight
1.95 kg
Application
Indoor
Tally Lamp
N/A
Security
Kensington Slot
Remote Control
Infrared
Operating Conditions
Temperature: 0 °C to +35 °C
Humidity: 20% to 80%
Storage Conditions
Temperature: -20 °C to +60 °C
Humidity: 20% to 95%
IP Streaming
Resolution
4K 30fps
Network Video Compress Formats
H.264, H.265
Maximum Frame Rate
4K 30fps
Network Interface
10 / 100 / 1000 Base-T
Multi-Stream Capability
2 (RTSP / Web Page), 4K 30fps (max.)
Network Protocols
IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
USB
Connector
USB 3.0
Video Format
MJPEG, YUY2
Audio Format
PCM
USB Video Class (UVC)
UVC 1.1
USB Audio Class (UAC)
UAC 1.0
Software Tools
IP Search and Configuration Tool
Support Windows® 7 or later
