Specifications
Camera
Image Sensor
1/2.8” 4K Sony Exmor CMOS
Effective Picture Elements
8 Megapixels
Output Resolutions
Resolution: 4K / 1080p / 720p
Frame Rates: 60 / 59.94 / 50 / 30 / 29.97 / 25
Minimum Illumination
0.7 lux (IRE50, F1.6, 30fps)
S / N Ratio
= 50 dB
Gain
Auto, Manual
TV Line
1000 (Center / Wide)
Shutter Speed
1/1 to 1/10,000 sec
Exposure Control
Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance
Auto, Manual
Optical Zoom
30X
Digital Zoom
1X
Total Zoom
30X
Viewing Angles
DFOV: 75.5° (Wide) to 3.1° (Tele)
HFOV: 68.0° (Wide) to 2.7° (Tele)
VFOV: 41.7° (Wide) to 1.5° (Tele)
Focal Length
f = 4.3 mm (Wide) to 129 mm (Tele)
Aperture (Iris)
F = 1.6 (Wide) to 4.7 (Tele)
Minimum Working Distance
0.1 m (Wide), 1.2 m (Tele)
Pan / Tilt Angles
Pan : ±170°, Tilt : ±90°
Preset Positions
10 (IR), 256 (IP)
Camera Control - Interface
USB, IP
Camera Control - Protocols
USB, VISCA, CGI (IP)
Image Processing
Mirror / Flip / Freeze / WDR / BLC
Image Stability
Yes
Power Frequencies
50 Hz, 60 Hz
AI Function
Modes
Face / Eyes Tracking, Fall / Bed Egress Detection
Privacy
Protection Modes
Local Privacy Mode, Mosaic Function
